ABB M3BP71MA6 Motors

ABB M3BP71MA6 Motors SPECIFICATIONS

Find the discount ABB M3BP71MA6 Motors online you need . 50,000 Bore Diameter (mm) We offer ... 50x130x31 If you check out our large selection of ABB M3BP71MA6 Motors once . 50x130x31 Size (mm)
Bearing number:7410BG
Size (mm):50x130x31
Bore Diameter (mm):50,000
Outer Diameter (mm):130,000
Width (mm):31,000
d:50,000 mm
D:130,000 mm
B:31,000 mm

Download ABB M3BP71MA6 Motors Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

Electric Motors Product Description

C:31,000 mm
Contact angle α:40 °
rs min:2.1 mm
r1s min:1.1 mm
Radial clearance class:CN
Mass:1.86 kg
Dynamic load, C:85 kN
Static load, C0:57.1 kN
Fatigue limit load, Cu:2.6 kN
Min operating temperature, Tmin:-40 °C
Max operating temperature, Tmax:120 °C
Characteristic cage frequency, FTF:0.4 Hz
Characteristic rolling element frequency, BSF:3.76 Hz
Characteristic outer ring frequency, BPF0:4.02 Hz
Characteristic inner ring frequency, BPFI:5.98 Hz
da min:286 mm
Da max:118 mm
Db max:123 mm
r1a max:1 mm
ra max:2 mm
Category:Angular Contact Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:1.87
Product Group:B00308
Enclosure:Open
Flush Ground:Yes
Rolling Element:Ball Bearing
Number of Rows of Balls:Single Row
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Snap Ring:No
Cage Material:Steel
Contact Angle:40 Degree
Internal Clearance:C0-Medium
Number of Bearings:1 (Single)
Mounting Arrangement:Universal
Inch - Metric:Metric
Long Description:50MM Bore; 130MM Outside Diameter; 31MM Width; Open; Yes Flush Ground; Ball Bearing; Single Row of Balls; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring
UNSPSC:31171531
Harmonized Tariff Code:8482.10.50.28
Noun:Bearing
Keyword String:Angular Contact
Manufacturer Item Number:7410BG
Weight / LBS:4.111
Width:1.22 Inch | 31 Millimeter
Bore:1.969 Inch | 50 Millimeter
Outside Diameter:5.118 Inch | 130 Millimeter
bore diameter::50 mm
radial static load capacity::57000 N
outside diameter::130 mm
operating temperature range::-40 to 120 ºC
overall width::31 mm
cage material::Brass
contact angle::40 °
outer ring width::31 mm
row type & fill slot::Single-Row Non-Fill Slot
maximum rpm::5600 rpm
internal clearance::C0
finish/coating::Uncoated
bore type::Round
precision rating::ISO Class 0
closure type::Open
fillet radius::2.1 mm
snap ring included::Without Snap Ring
series::74B
bearing material::High Carbon Chrome Steel
weight::1.860 kg
radial dynamic load capacity::85000 N
manufacturer product page::Click here
