INA GE20-AX MODELS

Need a CAD or 3D Model?

Contact Now WhatsApp Be Our Agent

INA GE20-AX

INA GE20-AX SPECIFICATIONS

INA GE20-AX, Units and Housings Flange Block Category CAD models , Plain Bearings 0.0 Inventory Manufacturing Service . Get Your Free.
Category:Flange Block
Inventory:0.0
Minimum Buy Quantity:N/A
Weight:3.048
Product Group:M06288
Number of Mounting Holes:4
Mounting Method:Concentric Collar
Housing Style:4 Bolt Square Flange Block

Download INA GE20-AX Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

INA GE20-AX Product Features

Rolling Element:Spherical Roller Bearing
Housing Material:Cast Iron
Expansion / Non-expansion:Non-expansion
Mounting Bolts:1/2 Inch
Relubricatable:Yes
Insert Part Number:INS-S2-106R
Seals:Triple Lip Contact
Housing Configuration:1 Piece Solid
Pilot Configuration:No Pilot
Inch - Metric:Inch
Long Description:4 Bolt Square Flange Block; 1-3/8" Bore; 4.9" Bolt Circle; 3-1/2" Bolt Spacing; 1 Piece Solid; Concentric Collar Mount; Cast Iron; Spherical Roller Bearing; 2.53" Length Thru Bore;
Other Features:Double Row | Has Flinger | With Set Screw
UNSPSC:31171501
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Flanged
Manufacturer Item Number:EF4B-S2-106R
Manufacturer Internal Number:071469
Weight / LBS:6.72
Nominal Bolt Circle Diameter Round:4.9 Inch | 125.7 Millimeter
Bolt Spacing:3.5 Inch | 88.9 Millimeter
Cartridge Pilot Diameter:0 Inch | 0 Millimeter
Cartridge Pilot Depth:0 Inch | 0 Millimeter
d:1.375 Inch | 34.925 Millimeter
D:2.53 Inch | 64.262 Millimeter
