NTN AELS206-103N

NTN AELS206-103N SPECIFICATIONS

Request A Quote For Your Special NTN AELS206-103N Needs Pillow Block Category Today! Free Mounted Units Quotes. ISO 0.0 Inventory 9001 certified.
Category:Pillow Block
Inventory:0.0
Minimum Buy Quantity:N/A
Weight:9.988
Product Group:M06288
Number of Mounting Holes:4
Mounting Method:Concentric Collar
Housing Style:4 Bolt Pillow Block

Download NTN AELS206-103N Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

Information techniques NTN AELS206-103N

Rolling Element:Spherical Roller Bearing
Housing Material:Cast Steel
Expansion / Non-expansion:Non-expansion
Mounting Bolts:5/8 Inch
Relubricatable:Yes
Insert Part Number:22215
Seals:Triple Lip Urethane
Housing Configuration:1 Piece Solid
Inch - Metric:Inch
Other Features:Double Row | Single Collar | With Set Screw
Long Description:4 Bolt Pillow Block; 2-3/4" Bore; 3-1/4" Base to Center Height; Concentric Collar Mount; Spherical Roller Bearing; 7.6" Minimum Bolt Spacing; 9.1" Bolt Spacing Maximum; Relubricata
UNSPSC:31171511
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Pillow Block
Weight / LBS:27
Bolt Spacing Minimum:7.6 Inch | 193.04Millimeter
d:2.75 Inch | 69.85 Millimeter
B:3.25 Inch | 82.55 Millimeter
Bolt Spacing Maximum:9.1 Inch | 231.14Millimeter
Nominal Bolt Center to Center:8.1 Inch | 206.4 Millimeter
D:3.62 Inch | 91.948 Millimeter
Actual Bolt Center to Center:0 Inch | 0Millimeter

NTN AELS206-103N pdf
