NTN AS206-104

NTN AS206-104 SPECIFICATIONS

QuestionNTN AS206-104 0.0 Inventory ? Find what you need faster by Flange Block Bearings Category entering your Mounted Units information .
Category:Flange Block Bearings
Inventory:0.0
Minimum Buy Quantity:N/A
Weight:127.78
Product Group:B04144
Number of Mounting Holes:4
Mounting Method:Clamp Collar
Housing Style:4 Bolt Round Flange Block

Download NTN AS206-104 Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

Information techniques NTN AS206-104

Rolling Element:Cylindrical Roller Bearing
Housing Material:Cast Iron
Expansion / Non-expansion:Non-Expansion
Mounting Bolts:24 Millimeter
Relubricatable:Yes
Insert Part Number:LSM190BR
Seals:Triple Lip Labyrinth
Housing Configuration:2 Piece Split
Pilot Configuration:No Pilot
Inch - Metric:Metric
Long Description:4 Bolt Round Flange Block; 190MM Bore; 474MM Bolt Circle; 2 Piece Split; Clamp Collar Mount; Cast Iron; Cylindrical Roller Bearing; 109MM Length Thru Bore; 335.2MM Bolt Spacing; Relubricatable; Triple
Other Features:Single Row | Wide Inner Ring | Light Duty
UNSPSC:31171501
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Flanged
Weight / LBS:281.45
D:4.291 Inch | 109 Millimeter
Cartridge Pilot Diameter:0 Inch | 0 Millimeter
d:7.48 Inch | 190 Millimeter
Bolt Spacing:13.2 Inch | 335.2 Millimeter
Nominal Bolt Circle Diameter Round:18.7 Inch | 474 Millimeter
Cartridge Pilot Depth:0 Inch | 0 Millimeter
Shaft Size:190 mm
Seal Type:Aluminium Triple Labyrinth
Bearing Type:Split Cylindrical Retained Type
Support Type:Round Flange
Series Type:Light Series
Bolt Size:4 x M24
Bearing Number:LSM190BR
Bearing - Housing - Seal:LSM190BRHATL
Bearing - Housing - Seal UPC:013992041401
Bearing UPC:013992029041
Dimension T:21.0 in
Dimension R:18.7 in
Dimension P:1.3 in
Dimension H:4.3 in
Dimension N:15.750 in
Dimension V:0.1 in
Dimension L:7.7 in
Cr - Dynamic Load Rating:138033 lbf
Cor - Static Load Rating:222561 lbf
Ca - Axial Load Rating:9217 lbf
Maximum Speed:1070 rpm
Note:This product line was formerly known as “Revolvo”
