Home>Products>Plain Bearings>NTN SFR1-16L

NTN SFR1-16L MODELS

Need a CAD or 3D Model?

Contact Now WhatsApp Be Our Agent

NTN SFR1-16L

NTN SFR1-16L SPECIFICATIONS

NTN SFR1-16L manufacturer and global supplier of reliable ball and roller ... Flange Block Category NTN SFR1-16L Industries Products Manufacturing & N/A Minimum Buy Quantity Engineering and Agricultural Bearings designed to meet the unique requirements of our targeted industries.
Category:Flange Block
Inventory:0.0
Minimum Buy Quantity:N/A
Weight:0.63
Product Group:M06110
Number of Mounting Holes:4
Mounting Method:Set Screw
Housing Style:4 Bolt Square Flange Block

Download NTN SFR1-16L Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

NTN SFR1-16L Product Features

Rolling Element:Ball Bearing
Housing Material:Thermoplastic
Expansion / Non-expansion:Non-expansion
Mounting Bolts:10 Millimeter
Relubricatable:Yes
Insert Part Number:SG2M30EL
Seals:Single Lip Contact
Housing Configuration:1 Piece Solid
Pilot Configuration:No Pilot
Inch - Metric:Metric
Long Description:4 Bolt Square Flange Block; 30MM Bore; 117MM Bolt Circle; 83MM Bolt Spacing; 1 Piece Solid; Set Screw Mount; Thermoplastic; Ball Bearing; 34.13MM Length Thru Bore; Relubricatable; Single Lip Contact S
Other Features:Single Row | Spherical | Intermediate Duty | White Housing | Closed End | Extended Inner Race | Food Grade Lubrication
UNSPSC:31171501
Harmonized Tariff Code:8483.20.40.40
Noun:Bearing
Keyword String:Flanged
Manufacturer Item Number:KLFS2M30DC
Manufacturer Internal Number:5896543
Weight / LBS:1.389
Cartridge Pilot Diameter:0 Inch | 0 Millimeter
d:1.181 Inch | 30 Millimeter
Bolt Spacing:3.268 Inch | 83 Millimeter
Cartridge Pilot Depth:0 Inch | 0 Millimeter
D:1.344 Inch | 34.13 Millimeter
Nominal Bolt Circle Diameter Round:4.6 Inch | 117 Millimeter

NTN SFR1-16L pdf
