Home>Products>Plain Bearings>NTN SFR1-8

NTN SFR1-8 MODELS

Need a CAD or 3D Model?

Contact Now WhatsApp Be Our Agent

NTN SFR1-8

NTN SFR1-8 SPECIFICATIONS

Request A Quote For Your Special NTN SFR1-8 Needs Today! Free Plain Bearings Take Up Units Category Quotes. ISO 0.0 Inventory 9001 certified.
Category:Take Up Units
Inventory:0.0
Minimum Buy Quantity:N/A
Weight:13.62
Product Group:M06288
Component Description:Take Up Bearing Only
Rolling Element:Spherical Roller Bearing
Housing Style:Unit Only

Download NTN SFR1-8 Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

NTN SFR1-8 Product Features

Mounting Method:V Lock
Compatible Take Up Frame:QMTF
Insert Part Number:22216
Housing Material:Cast Steel
Other Features:Double Row | Double Nut | Non-expansion | Three Lip Urethane Seal | Steel Cage
Inch - Metric:Inch
Long Description:Take Up Bearing Only; 2-11/16" Bore; 1-13/16" Slot Width; 5-15/16" Slot to Slot Distance; Spherical Roller Bearing; Unit Only; V Lock Mount; QMTF Take Up Frame; 22216 Insert Part; Cast
UNSPSC:31171533
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Take Up
Weight / LBS:35
d:2.688 Inch | 68.275 Millimeter
Slot Width:1.813 Inch | 46.05 Millimeter
Slot to Slot Distance:5.938 Inch | 150.825 Millimeter

NTN SFR1-8 pdf
