Home>Products>Plain Bearings>NTN SM1-10

NTN SM1-10 MODELS

Need a CAD or 3D Model?

Contact Now WhatsApp Be Our Agent

NTN SM1-10

NTN SM1-10 SPECIFICATIONS

Advance NTN SM1-10 is your source for quality N/A Minimum Buy Quantity Plain Bearings and accessories. shop online for home delivery or pick up in one of our 10000 . Flange Block Category
Category:Flange Block
Inventory:0.0
Minimum Buy Quantity:N/A
Weight:19.522
Product Group:M06288
Number of Mounting Holes:4
Mounting Method:Eccentric Collar
Housing Style:4 Bolt Round Flange Cartridge

Download NTN SM1-10 Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

NTN SM1-10 Product Features

Rolling Element:Spherical Roller Bearing
Housing Material:Cast Steel
Expansion / Non-expansion:Expansion
Mounting Bolts:3/4 Inch
Relubricatable:Yes
Insert Part Number:22220
Seals:Triple Lip Urethane
Housing Configuration:1 Piece Solid
Pilot Configuration:With Pilot
Inch - Metric:Inch
Long Description:4 Bolt Round Flange Cartridge; 3-15/16" Bore; 9.4" Bolt Circle; 6-5/8" Bolt Spacing; 1 Piece Solid; Eccentric Collar Mount; Cast Steel; Spherical Roller Bearing; 4.59" Length Thru
Other Features:Double Row
UNSPSC:31171501
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Flanged
Weight / LBS:43
d:3.938 Inch | 100.025 Millimeter
Cartridge Pilot Depth:0 Inch | 0 Millimeter
Cartridge Pilot Diameter:8.125 Inch | 206.375 Millimeter
Nominal Bolt Circle Diameter Round:9.4 Inch | 238 Millimeter
D:4.59 Inch | 116.586 Millimeter
Bolt Spacing:6.625 Inch | 168.275 Millimeter

NTN SM1-10 pdf
