NTN UC201D1

NTN UC201D1 SPECIFICATIONS

NTN UC201D1, Units and Housings CAD models Pillow Block Category , Mounted Units Manufacturing Service . Get Your Free.
Category:Pillow Block
Inventory:0.0
Minimum Buy Quantity:N/A
Weight:10.896
Product Group:M06288
Number of Mounting Holes:4
Mounting Method:V Lock
Housing Style:4 Bolt Pillow Block

Download NTN UC201D1 Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

Information techniques NTN UC201D1

Rolling Element:Spherical Roller Bearing
Housing Material:Cast Steel
Expansion / Non-expansion:Non-expansion
Mounting Bolts:5/8 Inch
Relubricatable:Yes
Insert Part Number:22215
Seals:Triple Lip Viton
Housing Configuration:1 Piece Solid
Inch - Metric:Inch
Other Features:Double Row | Single Nut | SN Style
Long Description:4 Bolt Pillow Block; 2-1/2" Bore; 3.15" Base to Center Height; V Lock Mount; Spherical Roller Bearing; 7.94" Minimum Bolt Spacing; 9.69" Bolt Spacing Maximum; Relubricatable; Cast
UNSPSC:31171511
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Pillow Block
Manufacturer Item Number:QVPG15V208SN
Weight / LBS:24
B:3.15 Inch | 80 Millimeter
Bolt Spacing Maximum:9.69 Inch | 246.126Millimeter
Nominal Bolt Center to Center:8.8 Inch | 223 Millimeter
Actual Bolt Center to Center:0 Inch | 0Millimeter
Bolt Spacing Minimum:7.94 Inch | 201.676Millimeter
d:2.5 Inch | 63.5 Millimeter
D:3.25 Inch | 82.55 Millimeter
