NTN UCF317D1

NTN UCF317D1 SPECIFICATIONS

LET OUR NTN UCF317D1 EXPERTS GET YOU Bearings Category THE PARTS YOU 0.0 Inventory NEED.
Category:Bearings
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / US pound:0.01
Product Group:M06110
Shaft Size:3.9375 in
Shaft Size Type:Imperial
Weight:59.0 lb

Download NTN UCF317D1 Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

Information techniques NTN UCF317D1

UPC Code:0883450507950
Type E Open Cover Number:EUDR-3 15/16
Nose Diameter:7.69 in
Nose Bore Diameter:6.37 in
Dimension B:6-1/4 in
Dimension H:10-7/8 in
Dimension A:4-1/2 in
Dimension N2:6.630 in
Dimension J:9-3/8 in
Dimension A3:1-1/2 in
Bolt Diameter:3/4 in
Dimension E:2-11/16 in
Dimension A1:1 in
Dimension D 1:8-1/8 in
Dimension d1:6-1/16 in
Dimension A2:1-13/16 in
Dimension Ac:5.925 in
Dimension d2:7.43 in
e:0.49
X (if Fa/Fr ≤ e):0.87
Y (if Fa/Fr ≤ e):1.77
X (if Fa/Fr > e):0.7
Y (if Fa/Fr > e):2.14
K Factor:1.23
C90 Dynamic Load Rating2:26900 lb
C0 Static Load Rating:154000 lb
Fa-max Maximum Permissible Thrust Load3:6908 lb
Fr-max Maximum Allowable Slip Fit Radial Load4:22000 lb
Max. Speed5:1530 rpm
Note:Note: All units have a 1/8 pipe thread grease fittingThe Maximum Permissible Thrust Load applies to conditions of slip fit with set screw mounting or in applications where a large moment loading occur
