NTN UCT205-100D1 MODELS

Need a CAD or 3D Model?

Contact Now WhatsApp Be Our Agent

NTN UCT205-100D1

NTN UCT205-100D1 SPECIFICATIONS

100% Authentic. NTN UCT205-100D1 N/A Minimum Buy Quantity Highest Quality. Certified Insert Bearings Category Supplier.
Category:Insert Bearings
Inventory:0.0
Minimum Buy Quantity:N/A
Weight:0.17
Product Group:M06110
Inner Race Profile:Narrow Inner Ring
Outer Race Profile:Spherical
Relubricatable:No

Download NTN UCT205-100D1 Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

Information techniques NTN UCT205-100D1

Seal Type:Single Lip Contour Riding
Mounting Method:Set Screw
Rolling Element:Ball Bearing
Snap Ring:No
Long Description:15/16" Bore; Narrow Inner Ring; Ball Bearing; 1-1/16" Length Thru Bore; 0.591" Outer Race Width; 2.047" Outside Diameter; Not Relubricatable; Single Lip Contour Riding Seal; Set Sc
Inch - Metric:Inch
Other Features:Single Row | Light Duty | Steel Cage
UNSPSC:31171536
Harmonized Tariff Code:8482.10.50.00
Noun:Bearing
Keyword String:Insert
Manufacturer Item Number:AS205-015
Weight / LBS:0.38
d:0.938 Inch | 23.825 Millimeter
D:2.047 Inch | 51.994 Millimeter
Outer Race Width:0.591 Inch | 15.011 Millimeter
bore diameter::0.9375 in
fillet radius::0.0394 in
outside diameter::2.0472 in
radial dynamic load capacity::3150 lbf
outer ring width::0.5906 in
radial static load capacity::1760 lbf
inner ring width::1.0630 in
bearing material::Through Hardened Steel
bore type::Round
finish/coating::Uncoated
locking device::Set Screw Collar
maximum rpm::5900 RPM
duty type::Standard Duty
seal type::Contact
overall width::1.0630 in
series::AS2
operating temperature range::-40 to 250 ºF
manufacturer product page::Click here

NTN UCT205-100D1 pdf
