DBDH10K1X/315V Rexroth Type DBDH Pressure Relief Valves

✖

Home>Products>Relief Valves>DBDH10K1X/315V Rexroth Type DBDH Pressure Relief Valves image

DBDH10K1X/315V Rexroth Type DBDH Pressure Relief Valves image

DBDH10K1X/315V Rexroth Type DBDH Pressure Relief Valves Codes and sizes

Number of Rows of Balls:Double Row
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Snap Ring:No
Cage Material:Steel
Contact Angle:30 Degree
Internal Clearance:C0-Medium
Number of Bearings:1 (Single)
Inch - Metric:Metric
Long Description:90MM Bore; 190MM Outside Diameter; 73MM Width; Open; No Flush Ground; Ball Bearing; Double Row of Balls; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; C0-Medium; Steel Cage; 30 Degree; 1 (Single)
UNSPSC:31171531
Harmonized Tariff Code:8482.10.50.28
Noun:Bearing
Keyword String:Angular Contact
Manufacturer Item Number:3318 A
Weight / LBS:19.114
D:190 mm
d:90 mm
B:73 mm
bore diameter::90 mm
operating temperature range::257 °F
outside diameter::190 mm
cage material::Steel
overall width::73 mm
maximum rpm::3400 rpm
contact angle::30 °
finish/coating::Uncoated
bore type::Round
fillet radius::3 mm
closure type::Open
series::33
bearing material::Steel
weight::20.4 lbs
radial dynamic load capacity::208 kN
manufacturer product page::Click here
radial static load capacity::180 kN
manufacturer upc number::7316570244632
d1 ≈:123.85 mm
D1 ≈:159.83 mm
r1,2 min.:3 mm
a:112 mm
da min.:104 mm
Da max.:176 mm
ra max.:2.5 mm
Basic dynamic load rating C:208 kN
Basic static load rating C0:180 kN
Fatigue load limit Pu:6.4 kN
Reference speed:3800 r/min
Limiting speed:3400 r/min
Calculation factor kr:0.07
Calculation factor e:0.8
Calculation factor X:0.63
Calculation factor Y0:0.66
Calculation factor Y1:0.78
Calculation factor Y2:1.24
Mass bearing:9.25 kg
