NG6 Cetop 3 Series Parallel Circuit Manifold - Leader Industrial Manufacture

✖

Home>Products>Product>NG6 Cetop 3 Series Parallel Circuit Manifold image

NG6 Cetop 3 Series Parallel Circuit Manifold image

NG6 Cetop 3 Series Parallel Circuit Manifold specification

Rolling Element:Cylindrical Roller Bearing
Housing Material:Cast Iron
Expansion / Non-expansion:Expansion
Mounting Bolts:30 Millimeter
Relubricatable:Yes
Insert Part Number:MSM180BX
Seals:Triple Lip Labyrinth
Housing Configuration:2 Piece Split
Pilot Configuration:No Pilot
Inch - Metric:Metric
Long Description:4 Bolt Round Flange Block; 180MM Bore; 524MM Bolt Circle; 2 Piece Split; Clamp Collar Mount; Cast Iron; Cylindrical Roller Bearing; 140MM Length Thru Bore; 370.5MM Bolt Spacing; Relubricatable; Triple
Other Features:Single Row | Wide Inner Ring | Medium Duty
UNSPSC:31171501
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Flanged
Weight / LBS:426.38
Cartridge Pilot Diameter:0 Inch | 0 Millimeter
Bolt Spacing:14.6 Inch | 370.5 Millimeter
Cartridge Pilot Depth:0 Inch | 0 Millimeter
D:5.512 Inch | 140 Millimeter
Nominal Bolt Circle Diameter Round:20.6 Inch | 524 Millimeter
d:7.087 Inch | 180 Millimeter
Shaft Size:180 mm
Seal Type:Aluminium Triple Labyrinth
Bearing Type:Split Cylindrical Expansion Type
Support Type:Round Flange
Series Type:Medium Series
Bolt Size:4 x M30
Bearing Number:MSM180BX
Bearing - Housing - Seal:MSM180BXHATL
Bearing - Housing - Seal UPC:013992058560
Bearing UPC:013992034151
Dimension T:23.5 in
Dimension R:20.6 in
Dimension P:1.3 in
Dimension H:5.1 in
Dimension N:17.500 in
Dimension V:0.2 in
Dimension L:9.5 in
Cr - Dynamic Load Rating:208398 lbf
Cor - Static Load Rating:305066 lbf
Maximum Speed:1120 rpm
Note:This product line was formerly known as “Revolvo”
