Differential Pressure Indicator TW Series image

Back to product page

Differential Pressure Indicator TW Series Codes and sizes

C:4 mm
r min.:0,2 mm
da min.:31,6 mm
da max:32,3 mm
Da max.:35,4 mm
ra max.:0,2 mm
Weight:0,006 Kg
Basic dynamic load rating (C):1,14 kN
Basic static load rating (C0):0,95 kN
(Grease) Lubrication Speed:3 300 r/min
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:0.008
Product Group:B00308
Enclosure:2 Seals
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Enclosure Type:Non-Contact Seal
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:30MM Bore; 37MM Outside Diameter; 4MM Outer Race Width; 2 Seals; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features; C0-Medium Internal Clearance; Steel Cage; N
Other Features:Deep Groove
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:6706LLF
Outside Diameter:1.457 Inch | 37 Millimeter
Inner Race Width:0 Inch | 0 Millimeter
Bore:1.181 Inch | 30 Millimeter
Outer Race Width:0.157 Inch | 4 Millimeter
bore diameter::30 mm
static load capacity::950 N
outside diameter::37 mm
precision rating::ISO Class 0
overall width::4 mm
finish/coating::Uncoated
bore type::Round
bearing material::High Carbon Chrome Steel
closure type::Double Sealed
cage material::Stainless Steel
row type & fill slot::Single Row Non-Fill Slot
inner ring width::4 mm
snap ring included::Without Snap Ring
outer ring width::4 mm
internal clearance::CN
maximum rpm (grease)::3300 rpm
operating temperature range::-40 to 140 ºC
fillet radius::0.2 mm
dynamic load capacity::1140 N
manufacturer product page::Click here
