DBDS20G1X/350E Rexroth Type DBDS Relief Valves - Leader Industrial Manufacture

✖

Home>Products>Relief Valves>DBDS20G1X/350E Rexroth Type DBDS Relief Valves image

DBDS20G1X/350E Rexroth Type DBDS Relief Valves image

DBDS20G1X/350E Rexroth Type DBDS Relief Valves Codes and sizes

Cage Material:Polyamide
Precision Class:ABEC 1 | ISO P0
Internal Clearance:C0-Medium
Number of Rows of Balls:Double Row
Other Features:Allowable Misalignment 3 Deg | High Capacity Design
Long Description:15MM Bore; Shaft Mount; 42MM Outside Diameter; 13MM Inner Race Width; 13MM Outer Race Width; Open; Polyamide Cage; Double Row of Balls; ABEC 1 | ISO P0; C0-Medium
Inch - Metric:Metric
UNSPSC:31171532
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Self Aligning
Manufacturer Item Number:1302 ETN9
Weight / LBS:0.207
Inner Race Width:0.512 Inch | 13 Millimeter
D:42 mm
Outer Race Width:0.512 Inch | 13 Millimeter
d:15 mm
bore diameter::15 mm
precision rating::Not Rated
outside diameter::42 mm
maximum rpm::24000 RPM
overall width::13 mm
cage material::Fiberglass Reinforced Nylon
bore type::Straight
finish/coating::Uncoated
closure type::Open
maximum misalignment::3 °
internal clearance::C0
outer ring width::13 mm
dynamic load capacity::10.8 kN
fillet radius::1 mm
static load capacity::2.6 kN
series::1300
B:13 mm
d1 ≈:23.9 mm
D1 ≈:34.3 mm
r1,2 min.:1 mm
da min.:20.6 mm
Da max.:36.4 mm
ra max.:1 mm
Basic dynamic load rating C:10.8 kN
Basic static load rating C0:2.6 kN
Fatigue load limit Pu:0.14 kN
Reference speed:34000 r/min
Limiting speed:24000 r/min
Permissible angular misalignment α:3 °
Calculation factor kr:0.04
Calculation factor e:0.31
Calculation factor Y0:2.2
Calculation factor Y1:2
Calculation factor Y2:3.1
Mass bearing:0.094 kg
