Products and services DMG-01-2D40B-10 Manually Operated Directional Valves

D1 - Flange Outer Diameter:27.2772 in
B - Cone Width:1.2500 in
C - Cup Width:1.0000 in
C1 - Cup Flange Width:0.2812 in
T1 - Bearing Width:1.250 in
T - Bearing Width to Flange:0.5312 in
R - Cone Backface To Clear Radius1:0.14 in
r - Cup Backface To Clear Radius2:0.130 in
da - Cone Frontface Backing Diameter:24.21 in
db - Cone Backface Backing Diameter:24.21 in
Da - Cup Frontface Backing Diameter:26.46 in
Ab - Cage-Cone Frontface Clearance:0.05 in
Aa - Cage-Cone Backface Clearance:0.01 in
a - Effective Center Location3:3.78 in
C90 - Dynamic Radial Rating (90 million revolutions)4:20000 lbf
C1 - Dynamic Radial Rating (1 million revolutions)5:77300 lbf
C0 - Static Radial Rating:217000 lbf
Ca90 - Dynamic Thrust Rating (90 million revolutions)6:18100 lbf
K - Factor7:1.11
e - ISO Factor8:0.53
Y - ISO Factor9:1.14
G1 - Heat Generation Factor (Roller-Raceway)10:3740
G2 - Heat Generation Factor (Rib-Roller End):1810
Cg - Geometry Factor11:0.223
