Hydac H-9601/13 Series Filter Elements - Leader Industrial Manufacture

✖

Home>Products>Filteration & Filter Elements>Hydac H-9601/13 Series Filter Elements image

Hydac H-9601/13 Series Filter Elements image

Specifications for Filteration & Filter Elements

Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Enclosure Type:Contact Seal
Internal Clearance:C3-Loose
Inch - Metric:Metric
Long Description:100MM Bore; 180MM Outside Diameter; 34MM Outer Race Diameter; 2 Seals; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:6220LLUC3/5C
Weight / LBS:6.92
Outer Race Width:1.339 Inch | 34 Millimeter
d:3.937 Inch | 100 Millimeter
D:7.087 Inch | 180 Millimeter
bore diameter::100 mm
static load capacity::93000 N
outside diameter::180 mm
precision rating::ISO Class 0
overall width::34 mm
finish/coating::Uncoated
bore type::Round
bearing material::High Carbon Chrome Steel
closure type::Double Sealed
cage material::Steel
row type & fill slot::Single Row Non-Fill Slot
inner ring width::34 mm
snap ring included::Without Snap Ring
outer ring width::34 mm
internal clearance::C3
maximum rpm (grease)::2300 rpm
operating temperature range::-40 to 120 ºC
fillet radius::2.1 mm
dynamic load capacity::122000 N
