SKF TU 1.11/16 TF - Leader Industrial Manufacture

✖

Home>Products>Mounted Units>SKF TU 1.11/16 TF image

SKF TU 1.11/16 TF image

Information techniques SKF TU 1.11/16 TF

Rolling Element:Cylindrical Roller Bearing
Housing Material:Cast Iron
Expansion / Non-expansion:Expansion
Mounting Bolts:16 Millimeter
Relubricatable:Yes
Insert Part Number:MSE312BX
Seals:Triple Lip Labyrinth
Housing Configuration:2 Piece Split
Pilot Configuration:No Pilot
Inch - Metric:Inch
Long Description:4 Bolt Round Flange Block; 3-3/4" Bore; 13.1" Bolt Circle; 2 Piece Split; Clamp Collar Mount; Cast Iron; Cylindrical Roller Bearing; 3.626" Length Thru Bore; 9.3" Bolt Spacing; Rel
Other Features:Single Row | Wide Inner Ring | Medium Duty
UNSPSC:31171501
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Flanged
Weight / LBS:106.7
d:3.75 Inch | 95.25 Millimeter
D:3.626 Inch | 92.1 Millimeter
Cartridge Pilot Depth:0 Inch | 0 Millimeter
Bolt Spacing:9.3 Inch | 236.2 Millimeter
Nominal Bolt Circle Diameter Round:13.1 Inch | 334 Millimeter
Cartridge Pilot Diameter:0 Inch | 0 Millimeter
Shaft Size:3.75 in
Seal Type:Aluminium Triple Labyrinth
Bearing Type:Split Cylindrical Expansion Type
Support Type:Round Flange
Series Type:Medium Series
Bolt Size:4 x M16
Bearing Number:MSE312BX
Bearing - Housing - Seal:MSE312BXHATL
Bearing - Housing - Seal UPC:013992038579
Bearing UPC:013992032287
Dimension T:15.0 in
Dimension R:13.1 in
Dimension P:0.9 in
Dimension H:3.6 in
Dimension N:10.875 in
Dimension V:0.1 in
Dimension L:6.5 in
Cr - Dynamic Load Rating:87226 lbf
Cor - Static Load Rating:110381 lbf
Maximum Speed:2130 rpm
Note:This product line was formerly known as “Revolvo”
