Information techniques SKF SY 2.15/16 RM

Number of Bearings:2 (1 Pair)
Contact Angle:15 Degree
Preload:Light
Raceway Style:1 Rib Outer Ring
Cage Material:Nylon
Rolling Element:Ball Bearing
Mounting Arrangement:Duplex-Back to Back
Flush Ground:Yes
Inch - Metric:Metric
Other Features:Single Row | Angular Contact
Long Description:60MM Bore; 110MM Outside Diameter; 44MM Width; Open Enclosure; ABEC 5 | ISO P5 Precision; Steel Ball Material; 2 (1 Pair) Bearings; 15 Degree Contact Angle; Nylon Cage Material; 1 Rib Outer Ring Racew
UNSPSC:31171531
Harmonized Tariff Code:8482.10.50.28
Noun:Bearing
Keyword String:Angular Contact Ball
Manufacturer Item Number:7212CDB/GNP5
Weight / LBS:3.351
B:1.732 Inch | 44 Millimeter
D:4.331 Inch | 110 Millimeter
d:2.362 Inch | 60 Millimeter
bore diameter::60 mm
precision rating::ISO Class 5
outside diameter::110 mm
cage material::Steel
overall width::44 mm
finish/coating::Uncoated
contact angle::15 °
inner ring width::22 mm
duplex type::Back to Back
maximum rpm (oil)::10000 rpm
closure type::Open
maximum rpm (grease)::7700 rpm
operating temperature range::-40 to 120 ºC
outer ring width::22 mm
radial dynamic load capacity::104000 N
fillet radius::1.5 mm
radial static load capacity::99000 N
manufacturer product page::Click here
bearing material::High Carbon Chrome Steel
