Information techniques INA PASE1-1/2

Seal Type:M Seal
Mounting Method:Set Screw
Rolling Element:Ball Bearing
Snap Ring:No
Long Description:1-7/16" Bore; Wide Inner Ring; Ball Bearing; 1.689" Length Thru Bore; 0.748" Outer Race Width; 2.835" Outside Diameter; Relubricatable; M Seal Seal; Set Screw Mounting Method
Inch - Metric:Inch
Other Features:Single Row | Medium Duty | Grub Screw | Has Flinger
UNSPSC:31171536
Harmonized Tariff Code:8482.10.50.00
Noun:Bearing
Keyword String:Insert
Manufacturer Item Number:YAR 207-107-2F
Weight / LBS:0.904
d:36.513 mm
D:72 mm
Outer Race Width:0.748 Inch | 18.999 Millimeter
bore diameter::1.4375 in
radial dynamic load capacity::25.5 kN
outside diameter::72 mm
radial static load capacity::15.3 kN
outer ring width::19 mm
finish/coating::Uncoated
inner ring width::42.9 mm
maximum rpm::5300 RPM
bore type::Round
seal type::Contact with Flinger
locking device::Set Screw
B:42.9 mm
C:19 mm
d1 ≈:46.1 mm
B4:6 mm
r1,2 min.:1 mm
s1:25.4 mm
Basic dynamic load rating C:25.5 kN
Basic static load rating C0:15.3 kN
Fatigue load limit Pu:0.655 kN
Limiting speed1):5300 r/min
Calculation factor f0:14
Mass complete bearing:0.42 kg
Thread grub screw G2:5/16-24 UNF
Hexagonal key size for grub screw N:3.969 mm
Recommended tightening torque for grub screw:6.5 N·m
