TIMKEN RAK 3/4 PT image

Information techniques TIMKEN RAK 3/4 PT

Rolling Element:Ball Bearing
Snap Ring:Yes
Internal Special Features:No
Cage Material:Steel
Internal Clearance:C3-Loose
Inch - Metric:Metric
Long Description:25MM Bore; 52MM Outside Diameter; 15MM Outer Race Diameter; 2 Metal Shields; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; Yes Snap Ring; No Internal Special Features
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:6205 2ZNRJEM
Weight / LBS:0.32
Outer Race Width:0.591 Inch | 15 Millimeter
D:2.047 Inch | 52 Millimeter
d:0.984 Inch | 25 Millimeter
bore diameter::25 mm
static load capacity::7.8 kN
outside diameter::52 mm
precision rating::ABEC 3 (ISO Class 6)
overall width::15 mm
finish/coating::Uncoated
bore type::Round
cage material::Steel
closure type::Double Shielded
outer ring width::15 mm
row type & fill slot::Single Row Non-Fill Slot
fillet radius::1 mm
snap ring included::With Snap Ring
maximum rpm::18000 RPM
internal clearance::C3
series::62
dynamic load capacity::14.8 kN
