Information techniques NTN UCP204D1

Seal Type:Double Triply
Mounting Method:Eccentric Collar
Rolling Element:Ball Bearing
Snap Ring:No
Long Description:1-3/8" Bore; Wide Inner Ring; Ball Bearing; 2.016" Length Thru Bore; 0.748" Outer Race Width; 2.835" Outside Diameter; Relubricatable; Double Triply Seal; Eccentric Collar Mounting
Inch - Metric:Inch
Other Features:Single Row | Standard Duty
UNSPSC:31171536
Harmonized Tariff Code:8482.10.50.00
Noun:Bearing
Keyword String:Insert
Manufacturer Item Number:G1106KPPB2 AG
Weight / LBS:1.26
Outer Race Width:0.748 Inch | 18.999 Millimeter
D:2.016 Inch | 51.206 Millimeter
d:1.375 Inch | 34.925 Millimeter
Shaft Size d:1 3/8 in
Bore Type:Cylindrical bore
Bearing Type:Ball Bearing
Material:Bearing Steel
Lubrication Type:Relubricatable
O.D. Type:Spherical OD
Dimension M:0.145 in
Dimension B2:0.673 in
Series:Industrial
Sub Series:G1…KPPB2,3,4
Outside Diameter D:2.835 in
Inner Ring Width B:37.7 mm
Outside Ring Width C:19.000 mm
Radius r:0.6 mm
Center of Bearing from End S:18.85 mm
Dimension S1:32.35 mm
Set Screw Size:3/8-16
Number of Set Screws:2
Angle between Set Screws:90 º
Dimension B1:2.016 in
Static Load Rating:3440 lbf
Dynamic Load Rating:6400 lbf
