Information techniques TIMKEN STB1 1/4S

Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Internal Clearance:C3-Loose
Inch - Metric:Metric
Long Description:65MM Bore; 140MM Outside Diameter; 33MM Outer Race Width; 2 Metal Shields; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features; C3-Loose Internal Clearance; Stee
Other Features:Deep Groove | Electric Motor Grade
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:6313ZZC3/EM
Weight / LBS:4.453
d:2.559 Inch | 65 Millimeter
D:5.512 Inch | 140 Millimeter
Inner Race Width:0 Inch | 0 Millimeter
Outer Race Width:1.299 Inch | 33 Millimeter
bore diameter::65 mm
precision rating::ISO Class 0
outside diameter::140 mm
finish/coating::Uncoated
overall width::33 mm
bearing material::High Carbon Chrome Steel
bore type::Round
cage material::Steel
closure type::Double Shielded
inner ring width::33 mm
row type & fill slot::Single Row Non-Fill Slot
outer ring width::33 mm
snap ring included::Without Snap Ring
maximum rpm (grease)::4900 rpm
internal clearance::C3
fillet radius::2.1 mm
operating temperature range::-40 to 120 ºC
maximum rpm::5800 RPM
dynamic load capacity::92500 N
series::63
static load capacity::60000 N
manufacturer product page::Click here
