TIMKEN MUA 1 3/16 - Leader Industrial Manufacture

✖

Home>Products>Mounted Units>TIMKEN MUA 1 3/16 image

TIMKEN MUA 1 3/16 image

Information techniques TIMKEN MUA 1 3/16

Mounting Method:Eccentric Collar
Rolling Element:Ball Bearing
Relubricatable:No
Seal Type:Double Land Riding Rubber Contact
Snap Ring:No
Inch - Metric:Inch
Long Description:1-1/4" Bore; Wide Inner Ring; 0.63" Outer Race Width; Cylindrical Outer Race Profile; 2.441" Outside Diameter; Eccentric Collar; Ball Bearing; 1-29/32" Length Thru Bore; No Relubri
Other Features:Single Row | Standard Duty
Outer Race Width:0.63 Inch | 16.002 Millimeter
D:1.906 Inch | 48.412 Millimeter
d:1.25 Inch | 31.75 Millimeter
Shaft Size d:1 1/4 in
Bore Type:Cylindrical bore
Bearing Type:Ball Bearing
Material:Bearing Steel
Lubrication Type:Non-Relubricatable
O.D. Type:Cylindrical OD
Dimension B2:0.626 in
Series:Industrial
Sub Series:1..KRR
Outside Diameter D:2.441 in
Inner Ring Width B:36.51 mm
Outside Ring Width C:16.000 mm
Radius r:0.6 mm
Center of Bearing from End S:18.3 mm
Dimension S1:30.1 mm
Set Screw Size:5/16-18
Number of Set Screws:2
Angle between Set Screws:90 º
Dimension B1:1.906 in
Static Load Rating:2530 lbf
Dynamic Load Rating:4850 lbf
