INA DL17 Characteristics

C:80 mm
Angle (α):40 °
a:170 mm
r min.:5 mm
r1 min.:2 mm
da min.:222 mm
ra max.:4 mm
Weight:53,1 Kg
Basic dynamic load rating (C):410 kN
Basic static load rating (C0):555 kN
(Grease) Lubrication Speed:1 400 r/min
Contact angle α:40 °
rs min:5 mm
r1s min:2 mm
Mass:53.1 kg
Dynamic load, C:410 kN
Static load, C0:555 kN
Fatigue limit load, Cu:14.3 kN
Nlim (oil):1,900 rpm
Nlim (grease):1,400 rpm
Min operating temperature, Tmin:-40 °C
Max operating temperature, Tmax:120 °C
da min:222 mm
db min:398 mm
Da max:410 mm
Db max:4 mm
r1a max:2 mm
ra max:4 mm
Category:Angular Contact Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:54.38
Product Group:B00308
Enclosure:Open
Flush Ground:No
Rolling Element:Ball Bearing
Number of Rows of Balls:Single Row
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Snap Ring:No
Cage Material:Steel
Contact Angle:40 Degree
Internal Clearance:C0-Medium
Number of Bearings:1 (Single)
Inch - Metric:Metric
Long Description:200MM Bore; 420MM Outside Diameter; 80MM Width; Open; No Flush Ground; Ball Bearing; Single Row of Balls; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring
UNSPSC:31171531
Harmonized Tariff Code:8482.10.50.28
Noun:Bearing
Keyword String:Angular Contact
Manufacturer Item Number:7340B
Weight / LBS:119.782
Bore:7.874 Inch | 200 Millimeter
Outside Diameter:16.535 Inch | 420 Millimeter
Width:3.15 Inch | 80 Millimeter
bore diameter::200 mm
radial static load capacity::555000 N
outside diameter::420 mm
operating temperature range::-40 to 120 ºC
overall width::80 mm
cage material::Brass
contact angle::40 °
maximum rpm::1900 rpm
row type & fill slot::Single-Row Non-Fill Slot
finish/coating::Uncoated
bore type::Round
precision rating::ISO Class 0
closure type::Open
fillet radius::5 mm
snap ring included::Without Snap Ring
weight::54.200 kg
bearing material::High Carbon Chrome Steel
manufacturer product page::Click here
radial dynamic load capacity::410000 N
