SKF C4F30ZM - Leader Industrial Manufacture

✖

SKF C4F30ZM image

Information techniques SKF C4F30ZM

Rolling Element:Spherical Plain
Material - Outer Member:Cast Iron
Material - Ball:Steel
Material - Liner:Steel
Relubricatable:Yes
Enclosure:Open
Other Features:3 Piece
Long Description:70MM Bore; 55.5MM House Width; Female Stud Profile; M65 X 1.5; Right Hand Thread Direction; Spherical Plain Bearing; Cast Iron Outer Member; Steel Bal
Inch - Metric:Metric
UNSPSC:31171508
Harmonized Tariff Code:8483.30.80.55
Noun:Bearing
Keyword 3:Rod End
Keyword String:Plain Spherical Rod End
Manufacturer Item Number:SIR 70 ES
Weight / LBS:20.723
Ball Width:1.929 Inch | 49 Millimeter
Housing Width:2.185 Inch | 55.5 Millimeter
d:70 mm
bore diameter::70 mm
ball material::Steel
misalignment angle::6 °
race material::Steel
shank thread length::66 mm
radial static load capacity::450 kN
rod end type::Female Threaded
operating temperature range::-50 to +300 °C
shank thread size::M65x1.5
head diameter::156 mm
thread direction::Right Hand
head width::55.5 mm
lubrication type::With Lubrication Fitting
ball width::49 mm
housing material::Cast Iron
length to ball center::150 mm
d2 max.:156.5 mm
B:49 mm
G:M 65x1.5
C1 max.:55.5 mm
h1:150 mm
α:6 °
dk:92 mm
d4 max.:87.5 mm
l3 min.:66 mm
l4 max.:234.5 mm
l7 min.:74 mm
N max.:130 mm
N1 max.:55.5 mm
r1 min.:1 mm
Size bolt with internal hexagon:M 16
Tightening torque bolt with internal hexagon:79 N·m
Basic dynamic load rating C:315 kN
Basic static load rating C0:450 kN
Specific dynamic load factor K:100 N/mm²
Material constant KM:330
Mass rod end:9.88 kg
