FAG BEARING 53308 Characteristics

Seal Type:Double Land Riding Rubber Contact
Mounting Method:Set Screw
Rolling Element:Ball Bearing
Snap Ring:No
Long Description:1" Bore; Narrow Inner Ring; Ball Bearing; 1-7/64" Length Thru Bore; 0.591" Outer Race Width; 2.047" Outside Diameter; Relubricatable; Double Land Riding Rubber Contact Seal; Set Sc
Inch - Metric:Inch
Other Features:Single Row | Standard Duty
UNSPSC:31171536
Harmonized Tariff Code:8482.10.50.00
Noun:Bearing
Keyword String:Insert
Manufacturer Item Number:GYA100RRB
Weight / LBS:0.38
Outer Race Width:0.591 Inch | 15.011 Millimeter
D:1.109 Inch | 28.169 Millimeter
d:1 Inch | 25.4 Millimeter
Shaft Size d:1 in
Bore Type:Cylindrical bore
Bearing Type:Ball Bearing
Material:Bearing Steel
Lubrication Type:Relubricatable
O.D. Type:Spherical OD
Dimension M:0.142 in
Series:Standard
Sub Series:GYA..RRB
Outside Diameter D:2.047 in
Inner Ring Width B:28.2 mm
Outside Ring Width C:15.000 mm
Radius r:0.6 mm
Center of Bearing from End S:8.84 mm
Dimension S1:19.36 mm
Set Screw Distance S2:6.35 mm
Set Screw Size:M6x1
Number of Set Screws:2
Angle between Set Screws:90 º
Static Load Rating:1750 lbf
Dynamic Load Rating:3490 lbf
