KOYO EE3 - Leader Industrial Manufacture

✖

KOYO EE3 image

KOYO EE3 Characteristics

Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Enclosure Type:Non-Contact Seal
Internal Clearance:C3-Loose
Inch - Metric:Metric
Long Description:10MM Bore; 30MM Outside Diameter; 9MM Outer Race Width; 2 Seals; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features; C3-Loose Internal Clearance; Steel Cage; No
Other Features:Deep Groove | Non-Friction Nitrile Rubber Seal | Electric Motor Grade
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:6200LLBC3/EM
Weight / LBS:0.071
d:0.394 Inch | 10 Millimeter
Inner Race Width:0 Inch | 0 Millimeter
Outer Race Width:0.354 Inch | 9 Millimeter
D:1.181 Inch | 30 Millimeter
bore diameter::10 mm
precision rating::ISO Class 0
outside diameter::30 mm
finish/coating::Uncoated
overall width::9 mm
bearing material::High Carbon Chrome Steel
bore type::Round
cage material::Steel
closure type::Double Sealed
inner ring width::9 mm
row type & fill slot::Single Row Non-Fill Slot
outer ring width::9 mm
snap ring included::Without Snap Ring
maximum rpm (grease)::25000 rpm
internal clearance::C3
fillet radius::0.6 mm
operating temperature range::-40 to 120 ºC
maximum rpm::30000 RPM
dynamic load capacity::5100 N
series::62
static load capacity::2390 N
manufacturer product page::Click here
