TIMKEN 59429RB-2 - Leader Industrial Manufacture

✖

TIMKEN 59429RB-2 image

Customers who bought this item also bought Roller Bearings

C:14 mm
Angle (α):15 °
Category:Precision Ball Bearings
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:0.22
Product Group:B04270
Enclosure:Open
Precision Class:ABEC 7 | ISO P4
Material - Ball:Steel
Number of Bearings:2 (1 Pair)
Contact Angle:15 Degree
Preload:Light
Raceway Style:1 Rib Outer Ring
Cage Material:Steel
Rolling Element:Ball Bearing
Mounting Arrangement:Duplex-Universal
Flush Ground:Yes
Inch - Metric:Metric
Other Features:Single Row | Angular Contact
Long Description:17MM Bore; 47MM Outside Diameter; 28MM Width; Open Enclosure; ABEC 7 | ISO P4 Precision; Steel Ball Material; 2 (1 Pair) Bearings; 15 Degree Contact Angle; Steel Cage Material; 1 Rib Outer Ring Racewa
UNSPSC:31171531
Harmonized Tariff Code:8482.10.50.28
Noun:Bearing
Keyword String:Angular Contact Ball
Manufacturer Item Number:7303CGD2/GNP4
Weight / LBS:0.485
Outside Diameter:1.85 Inch | 47 Millimeter
Bore:0.669 Inch | 17 Millimeter
Width:1.102 Inch | 28 Millimeter
bore diameter::17 mm
precision rating::ISO Class 4
outside diameter::47 mm
cage material::Phenolic
overall width::28 mm
finish/coating::Uncoated
contact angle::15 °
inner ring width::14 mm
duplex type::Universal Flush Ground
maximum rpm (oil)::27000 rpm
closure type::Open
maximum rpm (grease)::21000 rpm
operating temperature range::-40 to 120 ºC
outer ring width::14 mm
radial dynamic load capacity::25600 N
fillet radius::1 mm
radial static load capacity::16500 N
manufacturer product page::Click here
bearing material::High Carbon Chrome Steel
