NTN 33269 - Leader Industrial Manufacture

✖

NTN 33269 image

Customers who bought this item also bought Roller Bearings

Rolling Element:Cylindrical Roller Bearing
Housing Material:Cast Iron
Expansion / Non-expansion:Expansion
Mounting Bolts:12 Millimeter
Relubricatable:Yes
Insert Part Number:LSM45BX
Seals:Triple Lip Labyrinth
Housing Configuration:2 Piece Split
Pilot Configuration:No Pilot
Inch - Metric:Metric
Long Description:4 Bolt Round Flange Block; 45MM Bore; 180MM Bolt Circle; 2 Piece Split; Clamp Collar Mount; Cast Iron; Cylindrical Roller Bearing; 60MM Length Thru Bore; 127.3MM Bolt Spacing; Relubricatable; Triple L
Other Features:Single Row | Wide Inner Ring | Light Duty
UNSPSC:31171501
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Flanged
Weight / LBS:20.92
Nominal Bolt Circle Diameter Round:7.1 Inch | 180 Millimeter
D:2.362 Inch | 60 Millimeter
Cartridge Pilot Diameter:0 Inch | 0 Millimeter
d:1.772 Inch | 45 Millimeter
Bolt Spacing:5 Inch | 127.3 Millimeter
Cartridge Pilot Depth:0 Inch | 0 Millimeter
Shaft Size:45 mm
Seal Type:Aluminium Triple Labyrinth
Bearing Type:Split Cylindrical Expansion Type
Support Type:Round Flange
Series Type:Light Series
Bolt Size:4 x M12
Bearing Number:LSM45BX
Bearing - Housing - Seal:LSM45BXHATL
Bearing - Housing - Seal UPC:013992040015
Bearing UPC:013992029836
Dimension T:8.5 in
Dimension R:7.1 in
Dimension P:0.5 in
Dimension H:2.2 in
Dimension N:5.375 in
Dimension V:0.1 in
Dimension L:4.1 in
Cr - Dynamic Load Rating:18659 lbf
Cor - Static Load Rating:19558 lbf
Maximum Speed:4630 rpm
Note:This product line was formerly known as “Revolvo”
