Home>Products>Roller Bearings>TIMKEN 17886-2 image

TIMKEN 17886-2 image

Back to product page

Customers who bought this item also bought Roller Bearings

C:33 mm
r min.:2 mm
Da max.:341 mm
db min:289 mm
ra max.:2 mm
Weight:7,4 Kg
Basic dynamic load rating (C):137 kN
Basic static load rating (C0):177 kN
(Grease) Lubrication Speed:1 600 r/min
(Oil) Lubrication Speed:1 900 r/min
rs min:2 mm
Radial clearance class:CN
Mass:7.4 kg
Dynamic load, C:137 kN
Static load, C0:177 kN
Fatigue limit load, Cu:4.55 kN
f0:16.1
Nlim (oil):1,900 rpm
Nlim (grease):1,600 rpm
Min operating temperature, Tmin:-40 °C
Max operating temperature, Tmax:120 °C
Characteristic cage frequency, FTF:0.47 Hz
Characteristic rolling element frequency, BSF:14.63 Hz
Characteristic outer ring frequency, BPF0:11.18 Hz
Characteristic inner ring frequency, BPFI:12.82 Hz
da min:289 mm
Da max:341 mm
ra max:2 mm
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:7.11
Product Group:B00308
Enclosure:Open
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:280MM Bore; 350MM Outside Diameter; 33MM Outer Race Width; Open; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features; C0-Medium Internal Clearance; Steel Cage
Other Features:Deep Groove
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:6856
Weight / LBS:15.675
Outside Diameter:13.78 Inch | 350 Millimeter
Outer Race Width:1.299 Inch | 33 Millimeter
Bore:11.024 Inch | 280 Millimeter
Inner Race Width:0 Inch | 0 Millimeter
bore diameter::280 mm
precision rating::Class 0
outside diameter::350 mm
finish/coating::Uncoated
overall width::33 mm
bearing material::High Carbon Chrome Steel
bore type::Round
cage material::Brass
closure type::Open
inner ring width::33 mm
row type & fill slot::Single Row Non-Fill Slot
outer ring width::33 mm
snap ring included::Without Snap Ring
maximum rpm (grease)::1600 rpm
internal clearance::CN
maximum rpm (oil)::1900 rpm
operating temperature range::-40 to 120 ºC
fillet radius::2 mm
dynamic load capacity::137000 N
manufacturer product page::Click here
static load capacity::177000 N
