C:18,000 mm
a:34 mm
Contact angle α:40 °
rs min:1.1 mm
r1s min:0.6 mm
Radial clearance class:CN
Mass:0.38 kg
Dynamic load, C:32 kN
Static load, C0:23 kN
Fatigue limit load, Cu:1.05 kN
Nlim (oil):11,000 rpm
Nlim (grease):8,300 rpm
Min operating temperature, Tmin:-40 °C
Max operating temperature, Tmax:120 °C
da min:47 mm
db min:44.5 mm
Da max:73 mm
Db max:75.5 mm
r1a max:0.6 mm
ra max:1 mm
Category:Angular Contact Ball Bearing
Inventory:8.0
Minimum Buy Quantity:N/A
Weight / Kilogram:0.377
Product Group:B00308
Enclosure:Open
Flush Ground:Yes
Rolling Element:Ball Bearing
Number of Rows of Balls:Single Row
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Snap Ring:No
Cage Material:Steel
Contact Angle:40 Degree
Internal Clearance:C0-Medium
Number of Bearings:1 (Single)
Mounting Arrangement:Universal
Inch - Metric:Metric
Long Description:40MM Bore; 80MM Outside Diameter; 18MM Width; Open; Yes Flush Ground; Ball Bearing; Single Row of Balls; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring
UNSPSC:31171531
Harmonized Tariff Code:8482.10.50.28
Noun:Bearing
Keyword String:Angular Contact
Manufacturer Item Number:7208BG
Weight / LBS:0.833
Width:0.709 Inch | 18 Millimeter
Bore:1.575 Inch | 40 Millimeter
Outside Diameter:3.15 Inch | 80 Millimeter
bore diameter::40 mm
radial static load capacity::23000 N
outside diameter::80 mm
operating temperature range::-40 to 120 ºC
overall width::18 mm
cage material::Steel
contact angle::40 °
outer ring width::18 mm
row type & fill slot::Single-Row Non-Fill Slot
maximum rpm::11000 rpm
internal clearance::C0
finish/coating::Uncoated
bore type::Round
precision rating::ISO Class 0
closure type::Open
fillet radius::1.1 mm
snap ring included::Without Snap Ring
series::72B
bearing material::High Carbon Chrome Steel
weight::0.377 kg
radial dynamic load capacity::32000 N
