TIMKEN 748S-90026 - Leader Industrial Manufacture

✖

TIMKEN 748S-90026 image

Customers who bought this item also bought Roller Bearings

Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Enclosure Type:Contact Seal
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:20MM Bore; 42MM Outside Diameter; 12MM Outer Race Width; 2 Seals; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features; C0-Medium Internal Clearance; Steel Cage;
Other Features:Deep Groove | NBR Seal | Grease with Lithium Thickener
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:6004-2RSH/LHT23
Weight / LBS:0.165
d:0.787 Inch | 20 Millimeter
D:1.654 Inch | 42 Millimeter
Inner Race Width:0 Inch | 0 Millimeter
Outer Race Width:0.472 Inch | 12 Millimeter
bore diameter::20 mm
static load capacity::5 kN
outside diameter::42 mm
precision rating::Not Rated
overall width::12 mm
finish/coating::Uncoated
bore type::Round
cage material::Steel
closure type::Double Sealed
outer ring width::12 mm
row type & fill slot::Single Row Non-Fill Slot
fillet radius::0.6 mm
internal clearance::C0
maximum rpm::11000 RPM
operating temperature range::-40 to +210 °F
series::60
dynamic load capacity::9.95 kN
