TIMKEN 55206-90028 image

Back to product page

You Might Also Like

Customers who bought this item also bought Roller Bearings

C:34 mm
r min.:2,1 mm
da min.:111 mm
da max:122 mm
Da max.:169 mm
ra max.:2 mm
Weight:3,14 Kg
Basic dynamic load rating (C):122 kN
Basic static load rating (C0):93 kN
(Grease) Lubrication Speed:3 500 r/min
(Oil) Lubrication Speed:4 200 r/min
rs min:2.1 mm
Radial clearance class:CN
Mass:3.14 kg
Dynamic load, C:122 kN
Static load, C0:93 kN
Fatigue limit load, Cu:3.55 kN
f0:14.4
Nlim (oil):4,200 rpm
Nlim (grease):3,500 rpm
Min operating temperature, Tmin:-20 °C
Max operating temperature, Tmax:120 °C
Characteristic cage frequency, FTF:0.41 Hz
Characteristic rolling element frequency, BSF:5.33 Hz
Characteristic outer ring frequency, BPF0:4.09 Hz
Characteristic inner ring frequency, BPFI:5.91 Hz
da min:111 mm
Da max:169 mm
ra max:2 mm
bore diameter::100 mm
precision rating::Class 0
outside diameter::180 mm
finish/coating::Uncoated
overall width::34 mm
bearing material::High Carbon Chrome Steel
bore type::Round
cage material::Steel
closure type::Open
inner ring width::34 mm
row type & fill slot::Single Row Non-Fill Slot
outer ring width::34 mm
snap ring included::Without Snap Ring
maximum rpm (grease)::3500 rpm
internal clearance::CN
maximum rpm (oil)::4200 rpm
operating temperature range::-40 to 120 ºC
fillet radius::2.1 mm
dynamic load capacity::122000 N
manufacturer product page::Click here
static load capacity::93000 N
