FAG BEARING 23276-B-K-MB-T52BW - Leader Industrial Manufacture

✖

Home>Products>Roller Bearings>FAG BEARING 23276-B-K-MB-T52BW image

FAG BEARING 23276-B-K-MB-T52BW image

Customers who bought this item also bought Roller Bearings

Number of Rows of Rollers:Single Row
Separable:Outer Ring - Both Sides
Rolling Element:Cylindrical Roller Bearing
Profile:Complete with Outer and Inner Ring
Snap Ring:No
Internal Clearance:C0-Medium
Retainer:Yes
Relubricatable:Yes
Inch - Metric:Metric
Other Features:2 Rib Inner Ring | Plain Outer Ring | Cage on Inner Ring OD
Long Description:30MM Bore; Straight Bore Profile; 72MM Outside Diameter; 19MM Width; Steel Cage Matetrial; RBEC 1 | ISO P0; Single Row; Outer Ring - Both Sides Separable; No Snap Ring; Relubricatable; C0-Medium Inter
UNSPSC:31171547
Harmonized Tariff Code:8482.50.00.00
Noun:Bearing
Manufacturer Item Number:N306
Weight / LBS:0.77
B:0.748 Inch | 19 Millimeter
d:1.181 Inch | 30 Millimeter
D:2.835 Inch | 72 Millimeter
Enclosure:Open
Bore Type:Cylindrical Bore
Configuration:Single Row
Bore Size:30 mm
Outside Ring Inside Diameter:62 mm
Fillet Radius/Chamfer:1.1 mm
r1:1.1 mm
Dynamic Load Rating:38,500 N
Static Load Rating:35,000 N
Limiting Speed - Grease:8,500 rpm
Limiting Speed - Oil:11,000 rpm
Radial Clearance:0.020 to 0.045 mm
da (min):37 mm
db (min):37 mm
db (max):40 mm
dc (min):44 mm
Da (max):65 mm
Db (min):65 mm
Db (max):64 mm
ra (max):1 mm
ra1 (max):1 mm
