Home>Products>Roller Bearings>NTN 23952D1 image

NTN 23952D1 image

Back to product page

Customers who bought this item also bought Roller Bearings

d1:97.3 mm
D1:125.6 mm
F:89 mm
r1,2 - min.:2.1 mm
r3,4 - min.:2.1 mm
da - min.:82 mm
db - min.:100 mm
Da - max.:137.5 mm
ra - max.:2 mm
Basic dynamic load rating - C:315 kN
Basic static load rating - C0:325 kN
Fatigue load limit - Pu:41.5 kN
Reference speed:4800 r/min
Limiting speed:5600 r/min
Calculation factor - kr:0.25
Category:Cylindrical Roller Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:4.246
Product Group:B04144
Bore Profile:Straight
Cage Material:Polymer
Precision Class:RBEC 1 | ISO P0
Number of Rows of Rollers:Single Row
Separable:No
Rolling Element:Cylindrical Roller Bearing
Profile:Complete with Outer and Inner Ring
Snap Ring:No
Internal Clearance:C0-Medium
Retainer:Yes
Relubricatable:Yes
Inch - Metric:Metric
Other Features:High Capacity | 1 Rib Inner Ring with Side Plate | 2 Rib Outer Ring | Cage on Outer Ring ID
Long Description:70MM Bore; Straight Bore Profile; 150MM Outside Diameter; 51MM Width; Polymer Cage Matetrial; RBEC 1 | ISO P0; Single Row; Not Separable; No Snap Ring; Relubricatable; C0-Medium Internal Clearance; Re
UNSPSC:31171547
Harmonized Tariff Code:8482.50.00.00
Noun:Bearing
Manufacturer Item Number:NUP 2314 ECP
Weight / LBS:9.352
Outside Diameter:5.906 Inch | 150 Millimeter
Width:2.008 Inch | 51 Millimeter
Bore:2.756 Inch | 70 Millimeter
bore diameter::70 mm
precision rating::RBEC 1 (ISO Class Normal)
outside diameter::150 mm
maximum rpm::5600 RPM
overall width::51 mm
bearing material::Steel
flanges::(4) Flanges, Two-Piece Inner Ring
cage material::Polyamide
bore type::Straight
finish/coating::Uncoated
number of rows::1
closure type::Open
internal clearance::C0
application::Piston Type Machines, Rolling Mills, Spindles/Machine Tools
ring separation::Separable Ring
outer ring width::51 mm
operating temperature range::Maximum of +300 °F
fillet radius::2 mm
dynamic load capacity::315 kN
series::NUP23
static load capacity::325 kN
d1 ≈:97.3 mm
D1 ≈:125.6 mm
r1,2 min.:2.1 mm
r3,4 min.:2.1 mm
da min.:82 mm
db min.:100 mm
Da max.:137.5 mm
ra max.:2 mm
Basic dynamic load rating C:315 kN
Basic static load rating C0:325 kN
Fatigue load limit Pu:41.5 kN
Calculation factor kr:0.25
Limiting value e:0.3
Axial load factor Y:0.4
Mass bearing:4.17 kg
