Home>Products>Roller Bearings>FAG BEARING 22220-E1A-MA-T41A image

FAG BEARING 22220-E1A-MA-T41A image

Back to product page

Customers who bought this item also bought Roller Bearings

C:28 mm
r min.:2 mm
da min.:94 mm
da max:103 mm
Da max.:141 mm
ra max.:2 mm
Weight:1,79 Kg
Basic dynamic load rating (C):83,5 kN
Basic static load rating (C0):64 kN
(Grease) Lubrication Speed:4 200 r/min
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Product Group:B00308
Enclosure:2 Seals
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Enclosure Type:Non-Contact Seal
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:85MM Bore; 150MM Outside Diameter; 28MM Outer Race Width; 2 Seals; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features; C0-Medium Internal Clearance; Steel Cage;
Other Features:Deep Groove | Non-Friction Nitrile Rubber Seal | Shell Alvania Prelubricated
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Weight / LBS:3.96832
Outside Diameter:5.906 Inch | 150 Millimeter
Inner Race Width:0 Inch | 0 Millimeter
Bore:3.346 Inch | 85 Millimeter
Outer Race Width:1.102 Inch | 28 Millimeter
bore diameter::85 mm
static load capacity::64000 N
outside diameter::150 mm
precision rating::ISO Class 0
overall width::28 mm
finish/coating::Uncoated
bore type::Round
bearing material::High Carbon Chrome Steel
closure type::Double Sealed
cage material::Steel
row type & fill slot::Single Row Non-Fill Slot
inner ring width::28 mm
snap ring included::Without Snap Ring
outer ring width::28 mm
internal clearance::CN
maximum rpm (grease)::4200 rpm
operating temperature range::-40 to 120 ºC
fillet radius::2 mm
dynamic load capacity::83500 N
manufacturer product page::Click here
