SKF 21305 CC - Leader Industrial Manufacture

✖

SKF 21305 CC image

Customers who bought this item also bought Roller Bearings

Bore Profile:Tapered
Cage Material:Steel
Enclosure:Open
Number of Rows of Rollers:Double Row
Relubricatable:Yes
Withdrawal Sleeve:AH2236 (Specify bore)
Inch - Metric:Metric
Long Description:180MM Tapered Bore; 320MM Outside Diameter; 86MM Width; C3-Loose Clearance; Adapter Mount; Double Row of Spherical Roller Bearings; Steel Cage Material; Open Enclosure; Relubricatable; Adapter Part Nu
Other Features:Order adapter or withdrawal sleeve or nut separately. Others may be available
UNSPSC:31171510
Harmonized Tariff Code:84823080
Noun:Bearing
Keyword String:Spherical
Manufacturer Item Number:22236CDKE4C3
Weight / LBS:30
d:7.087 Inch | 180 Millimeter
B:3.386 Inch | 86 Millimeter
D:12.598 Inch | 320 Millimeter
Adapter Part Number:SNW3136 H3136 HA3136 HR3136 (Specify bore) Inch | H3136 (Specify bore) Millimeter
bore diameter::180 mm
maximum rpm::1300 RPM
outside diameter::320 mm
operating temperature range::Maximum of +200 °C
overall width::86 mm
cage material::Steel
bore type::Tapered 1:12
bearing material::Steel
outer ring type::Not Split
cage type::Inner Ring Guided
internal clearance::C3
precision rating::RBEC 1 (ISO Class Normal)
closure type::Open
finish/coating::Uncoated
lubrication hole type::Lubrication Groove & Hole
outer ring width::86 mm
dynamic load capacity::1020000 N
fillet radius::4 mm
static load capacity::1540000 N
series::222
