KOYO IR-1216 - Leader Industrial Manufacture

✖

KOYO IR-1216 image

Customers who bought this item also bought Roller Bearings

Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Internal Clearance:C3-Loose
Inch - Metric:Metric
Long Description:110MM Bore; 240MM Outside Diameter; 50MM Outer Race Diameter; Open; Ball Bearing; ABEC 1 | ISO P0; Yes Filling Slot; No Snap Ring; No Internal Special Features
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:322W
Weight / LBS:23.84
d:4.331 Inch | 110 Millimeter
D:9.449 Inch | 240 Millimeter
Outer Race Width:1.969 Inch | 50 Millimeter
Design Units:METRIC
Ball Type:STEEL
Bearing Weight:10.81 Kg
d - Bore:110 mm
D - Outer Diameter:240 mm
Bearing Width:50 mm
do - Ball Diameter:41.275 mm
Ce - Dynamic Radial Rating1:302000 N
C0 - Static Radial Rating:266000 N
Limiting Speed (Grease):1430 rpm
Limiting Speed (Oil):1710 rpm
R - Inner Ring To Clear Radius2:3.0 mm
r - Outer Ring To Clear Radius3:3.0 mm
da - Inner Ring Backing Diameter:124.0 mm
Da - Outer Ring Backing Diameter:226.100 mm
