IKO TLA3020Z - Leader Industrial Manufacture

✖

IKO TLA3020Z image

Customers who bought this item also bought Roller Bearings

T:47 mm
T2:28,5 mm
d3:110 mm
r min.:1 mm
r1 min.:1 mm
B:10 mm
D1:77 mm
Da max.:92 mm
ra max.:1 mm
rb max.:1 mm
Weight:1,54 Kg
Basic dynamic load rating (C):78 kN
Basic static load rating (C0):209 kN
(Grease) Lubrication Speed:1800 r/min
Category:Thrust Ball Bearings
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:1.57
Product Group:B00308
Rolling Element:Ball Bearing
Thrust Bearing:Yes
Single or Double Direction:Double Direction
Banded:No
Cage Material:Steel
Precision Class:Non-Precision
Component Description:Roller Assembly Plus Raceways
Other Features:Double Row | With Flat Seat
Long Description:60MM Bore 1; 77MM Bore 2; 110MM Outside Diameter; 47MM Height; Ball Bearing; Double Direction; Not Banded; Steel Cage; Non-Precision
Inch - Metric:Metric
UNSPSC:31171552
Harmonized Tariff Code:8482.10.50.08
Noun:Bearing
Keyword String:Ball Thrust
Manufacturer Item Number:52215
Weight / LBS:3.395
Bore 2:3.031 Inch | 77 Millimeter
Outside Diameter:4.331 Inch | 110 Millimeter
Bore 1:2.362 Inch | 60 Millimeter
Height:1.85 Inch | 47 Millimeter
Overall Height with Aligning Washer:0 Inch | 0 Millimeter
bore diameter::60 mm
static load capacity::21300 kg
outside diameter::110 mm
dynamic load capacity::7950 kg
overall width::47 mm
operating temperature range::Maximum of +120 °C
thrust bearing type::Double-Direction
maximum rpm::2600 RPM
outside diameter design::Straight
cage material::Steel
separable or banded::Separable
fillet radius::1 mm
race type::Flat
series::522
precision rating::ABEC 1 (ISO Class Normal)
