INA SL183056 - Leader Industrial Manufacture

✖

INA SL183056 image

Customers who bought this item also bought Roller Bearings

Number of Rows of Balls:Double Row
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Snap Ring:Yes
Cage Material:Steel
Contact Angle:25 Degree
Internal Clearance:C3-Loose
Number of Bearings:1 (Single)
Inch - Metric:Metric
Long Description:30MM Bore; 72MM Outside Diameter; 30.2MM Width; Open; No Flush Ground; Ball Bearing; Double Row of Balls; ABEC 1 | ISO P0; No Filling Slot; Yes Snap Ring; C3-Loose; Steel Cage; 25 Degree; 1 (Single)
Other Features:With Snap Ring
UNSPSC:31171531
Harmonized Tariff Code:8482.10.50.28
Noun:Bearing
Keyword String:Angular Contact
Manufacturer Item Number:5306NRC3
B:1.189 Inch | 30.2 Millimeter
d:1.181 Inch | 30 Millimeter
D:2.835 Inch | 72 Millimeter
bore diameter::30 mm
radial static load capacity::28100 N
outside diameter::72 mm
operating temperature range::-40 to 120 ºC
overall width::1.1875 in
cage material::Steel
contact angle::25 °
outer ring width::30.2 mm
row type & fill slot::Double-Row Non-Fill Slot
maximum rpm::8500 rpm
internal clearance::C3
finish/coating::Uncoated
bore type::Round
precision rating::Class 0
closure type::Open
fillet radius::1.1 mm
snap ring included::With Snap Ring
series::53
bearing material::High Carbon Chrome Steel
weight::0.557 kg
radial dynamic load capacity::40500 N
