d1: 43.75 mm
D2: 55.61 mm
r1,2 - min.: 1 mm
da - min.: 39.6 mm
da - max.: 43.7 mm
Da - max.: 57.4 mm
ra - max.: 1 mm
Basic dynamic load rating - C: 15.9 kN
Basic static load rating - C0: 10.2 kN
Fatigue load limit - Pu: 0.44 kN
Limiting speed: 7000 r/min
Calculation factor - kr: 0.025
Calculation factor - f0: 15
Category: Single Row Ball Bearing
Inventory: 0.0
Minimum Buy Quantity: N/A
Weight / Kilogram: 0.227
Product Group: B00308
Enclosure: 2 Seals
Precision Class: ABEC 1 | ISO P0
Maximum Capacity / Filling Slot: No
Rolling Element: Ball Bearing
Snap Ring: No
Internal Special Features: No
Cage Material: Steel
Enclosure Type: Contact Seal
Internal Clearance: C0-Medium
Inch - Metric: Metric
Long Description: 35MM Bore; 62MM Outside Diameter; 20MM Outer Race Diameter; 2 Seals; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features
Other Features: Cartridge Bearing
UNSPSC: 31171504
Harmonized Tariff Code: 8482.10.50.68
Noun: Bearing
Keyword String: Ball
Manufacturer Item Number: 63007-2RS1
Weight / LBS: 0.5
Bore: 1.378 Inch | 35 Millimeter
Outside Diameter: 2.441 Inch | 62 Millimeter
Outer Race Width: 0.787 Inch | 20 Millimeter
bore diameter:: 35 mm
static load capacity:: 10.2 kN
outside diameter:: 62 mm
precision rating:: ABEC 3 (ISO Class 6)
overall width:: 20 mm
finish/coating:: Uncoated
bore type:: Round
cage material:: Steel
closure type:: Double Sealed
outer ring width:: 20 mm
row type & fill slot:: Single Row Non-Fill Slot
fillet radius:: 1 mm
internal clearance:: C0
maximum rpm:: 7000 RPM
operating temperature range:: -40 to +210 °F
series:: 63
dynamic load capacity:: 15.9 kN
d1 ≈: 43.75 mm
D2 ≈: 55.61 mm
r1,2 min.: 1 mm
da min.: 39.6 mm
da max.: 43.7 mm
Da max.: 57.4 mm
ra max.: 1 mm
Basic dynamic load rating C: 15.9 kN
Basic static load rating C0: 10.2 kN
Fatigue load limit Pu: 0.44 kN
Calculation factor kr: 0.025
Calculation factor f0: 15
Mass bearing: 0.22 kg
