NTN 6002LLUC3 - Leader Industrial Manufacture

✖

NTN 6002LLUC3 image

NTN 6002LLUC3 Characteristics

C:19 mm
r min.:1,1 mm
da min.:36,5 mm
da max:42,5 mm
Da max.:65,5 mm
ra max.:1 mm
Weight:0,345 Kg
Basic dynamic load rating (C):26,7 kN
Basic static load rating (C0):15 kN
(Grease) Lubrication Speed:9 500 r/min
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:0.36
Product Group:B00308
Enclosure:2 Seals
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Enclosure Type:Non-Contact Seal
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:30MM Bore; 72MM Outside Diameter; 19MM Outer Race Diameter; 2 Seals; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:6306VV
Weight / LBS:0.345
Outer Race Width:0.748 Inch | 19 Millimeter
Bore:1.181 Inch | 30 Millimeter
Outside Diameter:2.835 Inch | 72 Millimeter
SRI:6.01
hidYobi:6306VV
LangID:1
D_:72
SREX:0.05
B_:19
da min:36.5
hidTable:ecat_NSRDGB
SRE:6.25
mass:0.345
GRS rpm:9500
ra:1
SRIX:0.025
D_a:65.5
C0:15
fo:13.3
DE_:63.906
Prod_Type3:DGBB_SR_VV
DA_:11.906
Z_:8
yobi:6306VV
C_conv:26700
SDM_:52
r:1.1
KBRG:6151
SBRG:3
DI_:40.094
