FAG BEARING 576875A.E18B.M27A.M30FF.M32AE - Leader Industrial Manufacture

✖

Home>Products>Plain Bearings>FAG BEARING 576875A.E18B.M27A.M30FF.M32AE image

FAG BEARING 576875A.E18B.M27A.M30FF.M32AE image

FAG BEARING 576875A.E18B.M27A.M30FF.M32AE Product Features

Number of Rows of Rollers:Single Row
Separable:Inner Ring - Both Sides
Rolling Element:Cylindrical Roller Bearing
Profile:Complete with Outer and Inner Ring
Snap Ring:No
Internal Clearance:C3-Loose
Retainer:Yes
Relubricatable:Yes
Inch - Metric:Metric
Other Features:Plain Inner Ring | 2 Rib Outer Ring | Cage on Outer Ring ID
Long Description:100MM Bore; Straight Bore Profile; 150MM Outside Diameter; 24MM Width; Brass Cage Matetrial; RBEC 1 | ISO P0; Single Row; Inner Ring - Both Sides Separable; No Snap Ring; Relubricatable; C3-Loose Inte
UNSPSC:31171547
Harmonized Tariff Code:8482.50.00.00
Noun:Bearing
Manufacturer Item Number:NU 1020 ML/C3
Weight / LBS:3.351
d:3.937 Inch | 100 Millimeter
D:5.906 Inch | 150 Millimeter
B:0.945 Inch | 24 Millimeter
bore diameter::100 mm
static load capacity::114 kN
outside diameter::150 mm
precision rating::Not Rated
overall width::24 mm
maximum rpm::7500 RPM
flanges::(2) Outer Ring
cage material::Brass
bore type::Straight
finish/coating::Uncoated
number of rows::1
closure type::Open
internal clearance::C3
outer ring width::24 mm
ring separation::Separable Ring
fillet radius::1.5 mm
operating temperature range::Maximum of +300 °F
series::NU10
dynamic load capacity::85.8 kN
