Home>Products>Ball Bearings>NTN 6209ZZC3/5C image

NTN 6209ZZC3/5C image

Back to product page

NTN 6209ZZC3/5C Characteristics

d2:9.5 mm
D2:16.5 mm
r1,2 - min.:0.3 mm
da - min.:8.4 mm
da - max.:9.4 mm
Da - max.:16.6 mm
ra - max.:0.3 mm
Basic dynamic load rating - C:2.3 kN
Basic static load rating - C0:0.95 kN
Fatigue load limit - Pu:0.04 kN
Limiting speed:24000 r/min
Calculation factor - kr:0.025
Calculation factor - f0:13
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:0.008
Product Group:B00308
Enclosure:2 Seals
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Enclosure Type:Contact Seal
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:6MM Bore; 19MM Outside Diameter; 6MM Outer Race Width; 2 Seals; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features; C0-Medium Internal Clearance; Steel Cage; Co
Other Features:Deep Groove | NBR Seal
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:626-2RSH
Weight / LBS:0.023
Outer Race Width:0.236 Inch | 6 Millimeter
Outside Diameter:0.748 Inch | 19 Millimeter
Inner Race Width:0 Inch | 0 Millimeter
Bore:0.236 Inch | 6 Millimeter
bore diameter::6 mm
static load capacity::0.95 kN
outside diameter::19 mm
precision rating::Not Rated
overall width::6 mm
finish/coating::Uncoated
bore type::Round
cage material::Steel
closure type::Double Sealed
outer ring width::6 mm
row type & fill slot::Single Row Non-Fill Slot
fillet radius::0.3 mm
internal clearance::C0
maximum rpm::24000 RPM
operating temperature range::-40 to +210 °F
series::62
dynamic load capacity::2.34 kN
d2 ≈:9.5 mm
D2 ≈:16.5 mm
da min.:8.4 mm
da max.:9.4 mm
Da max.:16.6 mm
ra max.:0.3 mm
Basic dynamic load rating C:2.34 kN
Basic static load rating C0:0.95 kN
Fatigue load limit Pu:0.04 kN
Calculation factor kr:0.025
Calculation factor f0:13
Mass bearing:0.0083 kg
