NTN 111 - Leader Industrial Manufacture

✖

NTN 111 image

NTN 111 Characteristics

Rolling Element:Cylindrical Roller Bearing
Housing Material:Cast Iron
Expansion / Non-expansion:Expansion
Mounting Bolts:16 Millimeter
Relubricatable:Yes
Insert Part Number:LSE311BX
Seals:Triple Lip Labyrinth
Housing Configuration:2 Piece Split
Pilot Configuration:No Pilot
Inch - Metric:Inch
Long Description:4 Bolt Round Flange Block; 3-11/16" Bore; 11.9" Bolt Circle; 2 Piece Split; Clamp Collar Mount; Cast Iron; Cylindrical Roller Bearing; 3.346" Length Thru Bore; 8.4" Bolt Spacing; R
Other Features:Single Row | Wide Inner Ring | Light Duty
UNSPSC:31171501
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Flanged
Weight / LBS:80.45
Bolt Spacing:8.4 Inch | 213.5 Millimeter
Cartridge Pilot Diameter:0 Inch | 0 Millimeter
d:3.688 Inch | 93.675 Millimeter
D:3.346 Inch | 85 Millimeter
Nominal Bolt Circle Diameter Round:11.9 Inch | 302 Millimeter
Cartridge Pilot Depth:0 Inch | 0 Millimeter
Shaft Size:3-11/16 in
Seal Type:Aluminium Triple Labyrinth
Bearing Type:Split Cylindrical Expansion Type
Support Type:Round Flange
Series Type:Light Series
Bolt Size:4 x M16
Bearing Number:LSE311BX
Bearing - Housing - Seal:LSE311BXHATL
Bearing - Housing - Seal UPC:013992039613
Bearing UPC:013992058935
Dimension T:14.0 in
Dimension R:11.9 in
Dimension P:0.7 in
Dimension H:3.4 in
Dimension N:9.625 in
Dimension V:0.1 in
Dimension L:6.0 in
Cr - Dynamic Load Rating:64745 lbf
Cor - Static Load Rating:82280 lbf
Maximum Speed:2340 rpm
Note:This product line was formerly known as “Revolvo”
