SKF 216SG - Leader Industrial Manufacture

✖

SKF 216SG image

SKF 216SG Characteristics

C:47 mm
r min.:3 mm
da min.:113 mm
da max:133 mm
Da max.:202 mm
ra max.:2,5 mm
Weight:7 Kg
Basic dynamic load rating (C):173 kN
Basic static load rating (C0):141 kN
Reference speed:2 200 r/min
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:7.19
Product Group:B00308
Enclosure:2 Seals
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Enclosure Type:Contact Seal
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:100MM Bore; 215MM Outside Diameter; 47MM Outer Race Width; 2 Seals; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features; C0-Medium Internal Clearance; Steel Cage
Other Features:Deep Groove | Double Lip Friction Nitrile Rubber Seal | -20 To 120 Deg C | Shell Alvania Prelubricated
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Weight / LBS:15.4
Inner Race Width:0 Inch | 0 Millimeter
Bore:3.937 Inch | 100 Millimeter
Outer Race Width:1.85 Inch | 47 Millimeter
Outside Diameter:8.465 Inch | 215 Millimeter
