SKF 1910S - Leader Industrial Manufacture

✖

SKF 1910S image

SKF 1910S Characteristics

Bore Profile:Straight
Cage Material:Bronze
Enclosure:Open
Number of Rows of Rollers:Double Row
Relubricatable:Yes
Withdrawal Sleeve:Not Applicable
Withdrawal Nut:Not Applicable
Inch - Metric:Metric
Long Description:260MM Straight Bore; 480MM Outside Diameter; 130MM Width; C0-Medium Clearance; Shaft Mount; Double Row of Spherical Roller Bearings; Bronze Cage Material; Open Enclosure; Relubricatable
UNSPSC:31171510
Harmonized Tariff Code:84823080
Noun:Bearing
Keyword String:Spherical
Weight / LBS:262.901
D:480 mm
Adapter Part Number:Not Applicable Inch | Not Applicable Millimeter
B:130 mm
d:260 mm
bore diameter::260 mm
maximum rpm::1600 RPM
outside diameter::480 mm
operating temperature range::Maximum of +390 °F
overall width::130 mm
cage material::Brass
bore type::Straight
bearing material::Steel
outer ring type::Not Split
cage type::Inner Ring Guided
internal clearance::C0
precision rating::Not Rated
closure type::Open
finish/coating::Uncoated
lubrication hole type::Lubrication Groove & Hole
outer ring width::130 mm
dynamic load capacity::2650 kN
fillet radius::4 mm
static load capacity::3550 kN
series::222
d2 ≈:329 mm
D1 ≈:421 mm
b:22.3 mm
K:12 mm
r1,2 min.:5 mm
da min.:280 mm
Da max.:460 mm
ra max.:4 mm
Basic dynamic load rating C:2722 kN
Basic static load rating C0:3550 kN
Fatigue load limit Pu:285 kN
Reference speed:1200 r/min
Limiting speed:1600 r/min
Calculation factor e:0.27
Calculation factor Y1:2.5
Calculation factor Y2:3.7
Calculation factor Y0:2.5
Mass bearing:110 kg
