SKF 1222 - Leader Industrial Manufacture

✖

SKF 1222 image

SKF 1222 Characteristics

C:10 mm
r min.:0,6 mm
da min.:84 mm
da max:84,5 mm
Da max.:96 mm
ra max.:0,6 mm
Weight:0,151 Kg
Basic dynamic load rating (C):12,7 kN
Basic static load rating (C0):14,5 kN
(Grease) Lubrication Speed:3 400 r/min
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:0.15
Product Group:B00308
Enclosure:2 Seals
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Enclosure Type:Contact Seal
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:80MM Bore; 100MM Outside Diameter; 10MM Outer Race Width; 2 Seals; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features; C0-Medium Internal Clearance; Steel Cage;
Other Features:Deep Groove | Rubber Seal
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:6816DDU
Weight / LBS:0.333
Bore:3.15 Inch | 80 Millimeter
Inner Race Width:0 Inch | 0 Millimeter
Outer Race Width:0.394 Inch | 10 Millimeter
Outside Diameter:3.937 Inch | 100 Millimeter
SRI:2.88
hidYobi:6816DDU
LangID:1
D_:100
SREX:0.015
B_:10
da min:84
hidTable:ecat_NSRDGB
SRE:2.88
mass:0.151
GRS rpm:3400
ra:0.6
SRIX:0.015
D_a:96
SRIN:-0.015
C0:14.5
fo:17.4
SREN:-0.015
DE_:95.556
Prod_Type3:DGBB_SR_DD
DA_:5.556
Z_:27
yobi:6816DDU
C_conv:12700
SDM_:90
r:0.6
KBRG:6161
SBRG:18
DI_:84.444
