TIMKEN 3MM208WI DUM Characteristics

D1:234.2 mm
F:167 mm
r1,2 - min.:4 mm
r3,4 - min.:4 mm
s:3.7 mm
da - min.:147 mm
da - max.:163 mm
db - min.:170 mm
Da - max.:261.4 mm
ra - max.:3 mm
rb - max.:3 mm
Basic dynamic load rating - C:720 kN
Basic static load rating - C0:750 kN
Fatigue load limit - Pu:81.5 kN
Reference speed:2400 r/min
Limiting speed:3000 r/min
Calculation factor - kr:0.15
Category:Cylindrical Roller Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:16.405
Product Group:B04144
Bore Profile:Straight
Cage Material:Polymer
Precision Class:RBEC 1 | ISO P0
Number of Rows of Rollers:Single Row
Separable:Inner Ring - Both Sides
Rolling Element:Cylindrical Roller Bearing
Profile:Complete with Outer and Inner Ring
Snap Ring:No
Internal Clearance:C0-Medium
Retainer:Yes
Relubricatable:Yes
Inch - Metric:Metric
Other Features:High Capacity | Plain Inner Ring | 2 Rib Outer Ring | Cage on Outer Ring ID
Long Description:130MM Bore; Straight Bore Profile; 280MM Outside Diameter; 58MM Width; Polymer Cage Matetrial; RBEC 1 | ISO P0; Single Row; Inner Ring - Both Sides Separable; No Snap Ring; Relubricatable; C0-Medium I
UNSPSC:31171547
Harmonized Tariff Code:8482.50.00.00
Noun:Bearing
Manufacturer Item Number:NU 326 ECP
Weight / LBS:36.134
Outside Diameter:11.024 Inch | 280 Millimeter
Bore:5.118 Inch | 130 Millimeter
Width:2.283 Inch | 58 Millimeter
bore diameter::130 mm
static load capacity::750 kN
outside diameter::280 mm
precision rating::Not Rated
overall width::58 mm
maximum rpm::3000 RPM
flanges::(2) Outer Ring
bearing material::Steel
bore type::Straight
cage material::Polyamide
number of rows::1
finish/coating::Uncoated
internal clearance::C0
closure type::Open
ring separation::Separable Ring
outer ring width::58 mm
operating temperature range::Maximum of +300 °F
fillet radius::3 mm
dynamic load capacity::720 kN
series::NU3
D1 ≈:234.2 mm
r1,2 min.:4 mm
r3,4 min.:4 mm
s max.:3.7 mm
da min.:147 mm
da max.:163 mm
db min.:170 mm
Da max.:261.4 mm
ra max.:3 mm
rb max.:3 mm
Basic dynamic load rating C:720 kN
Basic static load rating C0:750 kN
Fatigue load limit Pu:81.5 kN
Calculation factor kr:0.15
Limiting value e:0.2
Axial load factor Y:0.6
Mass bearing:16.1 kg
