NTN TSX1-63208ZZAC4P#01 - Leader Industrial Manufacture

✖

Home>Products>Ball Bearings>NTN TSX1-63208ZZAC4P#01 image

NTN TSX1-63208ZZAC4P#01 image

NTN TSX1-63208ZZAC4P#01 Characteristics

Rolling Element:Cylindrical Roller Bearing
Housing Material:Cast Iron
Expansion / Non-expansion:Non-Expansion
Mounting Bolts:24 Millimeter
Relubricatable:Yes
Insert Part Number:LSE700BR
Seals:Triple Lip Labyrinth
Housing Configuration:2 Piece Split
Pilot Configuration:No Pilot
Inch - Metric:Inch
Long Description:4 Bolt Round Flange Block; 7" Bore; 17.2" Bolt Circle; 2 Piece Split; Clamp Collar Mount; Cast Iron; Cylindrical Roller Bearing; 4.291" Length Thru Bore; 12.2" Bolt Spacing; Relubr
Other Features:Single Row | Wide Inner Ring | Light Duty
UNSPSC:31171501
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Flanged
Weight / LBS:225.79
Cartridge Pilot Diameter:0 Inch | 0 Millimeter
Cartridge Pilot Depth:0 Inch | 0 Millimeter
d:7 Inch | 177.8 Millimeter
Bolt Spacing:12.2 Inch | 309.7 Millimeter
D:4.291 Inch | 109 Millimeter
Nominal Bolt Circle Diameter Round:17.2 Inch | 438 Millimeter
Shaft Size:7 in
Seal Type:Aluminium Triple Labyrinth
Bearing Type:Split Cylindrical Retained Type
Support Type:Round Flange
Series Type:Light Series
Bolt Size:4 x M24
Bearing Number:LSE700BR
Bearing - Housing - Seal:LSE700BRHATL
Bearing - Housing - Seal UPC:013992046604
Bearing UPC:013992027504
Dimension T:20.0 in
Dimension R:17.2 in
Dimension P:1.1 in
Dimension H:4.3 in
Dimension N:14.375 in
Dimension V:0.1 in
Dimension L:7.7 in
Cr - Dynamic Load Rating:117800 lbf
Cor - Static Load Rating:186142 lbf
Ca - Axial Load Rating:8183 lbf
Maximum Speed:1220 rpm
Note:This product line was formerly known as “Revolvo”
